5 MP Varifocal Dome TVI Camera AC326D-OD4Z

Original price - Original price
Original price
-
Current price

Main Features

High quality solution for surveillance applications that demand high color imaging

  • 5 MP high-performance COMS
  • 2560 × 1944 resolution
  • 2.7 mm to 13.5 mm motorized varifocal lens
  • EXIR 2.0, smart IR, up to 40 m IR distance
  • OSD menu, 2D DNR, DWDR
  • 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
  • IP67, IK10
  • Up the coax (UTC-C)
  • 2 Years Warranty

Display & Graphics

Perfect Imagery Capturing - Advanced Digital Image System is a concept with a goal to improve surveillance and deliver the highest level of image quality

  • Effective Camera Resolution: 2560 (H) × 1944 (V)
  • Image Sensor: 5MP CMOS
  • Min. illumination: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
  • Shutter Time: PAL: 1/25 s to 1/50, 000 s; NTSC: 1/30 s to 1/50, 000 s

Physical Characteristics:

  • Form Factor: Dome
  • Dimension: 145.2 mm × 124.1 mm (7.1" × 4.9")
  • Weight: Approx. 655g(1.44 lb)
  • Horizontal Field of View: 95.7° to 29.1°
  • Operating Conditions: -40 °C - 60 °C, Humidity 90% or less (non-condensing)
  • Power Supply: 12 VDC±15%; Power Consumption: Max. 6.0W

Accessories:

DS-1273ZJ-140 Wall Mount

DS-1275ZJ-SUS Vertical Pole Mount

DS-1265ZJ-SUS Corner Mount

DS-1273ZJ-L Rain Shade

DS-1273ZJ-140B Wall Mount

DS-1241ZJ In-ceiling Mount

DS-1240ZJ Inclined Ceiling Mount



Download Data Sheet
