Main Features

NCA1C-FEA is a fisheye network camera capable of providing a 360-degree panoramic image of its surveillance scene. The progressive scan CMOS sensor provides high-resolution images of up to 4000 × 3000. Up to 18 live view display modes, designed for 3 mount types, meet various user preference.Three independently controlled IR lights offer a range of 15 m and provide good vision in low or even zero-light environment.

• 1/1.7” Progressive Scan CMOS
• Max. 4000 × 3000 @20fps
• Up to 18 live view display modes
• Digital WDR
• Up to 15m IR range
• Built-in microphone and speaker
• Smart features 6 behavior analyses, and 3 exception detections. Heat map with deep learning algorithm Intersection analysis by deep learning
• Panomorph lens RPL: B9VVT
• 3 years Warranty

Display & Graphics

The progressive scan CMOS sensor provides high-resolution images of up to 4000 × 3000.

• Effective Camera Resolution: 4000 x 3000 (max.)
• Image Sensor: 1/1.7'' Progressive Scan CMOS
• Min. illumination: Color: 0.06 Lux @ (F2.4, AGC ON); B/W: 0.012 Lux @ (F2.4, AGC ON)
• Shutter Speed: 1 s to 1/100,000 s

Physical Characteristics:

• Form Factor: Fisheye
• Dimension: 167 × 152.8 × 55 mm (6. 6" × 6" × 2.2")
• Weight: 1400g (3.09 lbs)
• Operating Conditions: -40 °C - 60 °C, Humidity 95% or less
• Power Supply: 12 VDC±20%; Power Consumption: Max. 12.5W

Accessories:

DS-1280ZJ-DM25 Junction Box

DS-1281ZJ-DM25 Inclined Ceiling Mount

DS-1273Zj-DM25 Wall Mount

DS-1271ZJ-DM25 Pendant Mount

DS-1283ZJ Wall Mount (3-axis Adjustment)
